Influence of the Ringer's solution on wear of vacuum mixed poly(methyl methacrylate) bone cement in reciprocating sliding contact with AISI 316L stainless steel Original scientific paper
Article Sidebar
Main Article Content
Abstract
This paper presents microstructural properties and damage behaviour of a vacuum mixed poly(methyl metacrylate) (PMMA) bone cement, during the sliding contact with AISI 316L stainless steel, under micro-loads. Influence of the Ringer's solution on the wear was analysed in comparison to dry contact. The variation of load did not produce any significant change of the wear factor while the increase in the sliding speed induced significant increases in the wear factor, more pronounced in the case of dry sliding. The obtained wear factors were in average higher for the sliding in Ringer's solution than those obtained under dry conditions. Significant fragmentation of the worn tracks, of irregular shapes with broken edges, was observed, slightly more pronounced for the dry contact. Many cavities and voids were formed on the wear track surface, but they did not extend into the bulk material. Higher loads produced more uniform and less fragmented wear tracks. Abrasive, adhesive wear and plastic deformation grooves were observed, as well as fatigue and erosive wear. Fatigue cracks developed in the direction normal to sliding. Network of fine craze cracks was exhibited on the surface of wear tracks, especially pronounced in the case of dry sliding. These results are important since they contribute to understanding the sites of crack initiation, and development mechanisms on the surface of PMMA bone cements, also including synergistic effects of physiological environments pertaining to the non-steady crack and craze behaviour and crack pattern development in PMMA.
Article Details
Issue
Section
This work is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International License.
Authors who publish with this journal agree to the following terms:Authors retain copyright and grant the journal right of first publication with the work simultaneously licensed under a Creative Commons Attribution License that allows others to share the work with an acknowledgement of the work's authorship and initial publication in this journal.
Authors grant to the Publisher the following rights to the manuscript, including any supplemental material, and any parts, extracts or elements thereof:
- the right to reproduce and distribute the Manuscript in printed form, including print-on-demand;
- the right to produce prepublications, reprints, and special editions of the Manuscript;
- the right to translate the Manuscript into other languages;
- the right to reproduce the Manuscript using photomechanical or similar means including, but not limited to photocopy, and the right to distribute these reproductions;
- the right to reproduce and distribute the Manuscript electronically or optically on any and all data carriers or storage media – especially in machine readable/digitalized form on data carriers such as hard drive, CD-Rom, DVD, Blu-ray Disc (BD), Mini-Disk, data tape – and the right to reproduce and distribute the Article via these data carriers;
- the right to store the Manuscript in databases, including online databases, and the right of transmission of the Manuscript in all technical systems and modes;
- the right to make the Manuscript available to the public or to closed user groups on individual demand, for use on monitors or other readers (including e-books), and in printable form for the user, either via the internet, other online services, or via internal or external networks.
How to Cite
References
Boote AT, Bigsby RJ, Deehan DJ, Rankin KS, Swailes DC, Hyde PJ. Does vacuum mixing affect diameter shrinkage of a PMMA cement mantle during in vitro cemented acetabulum implantation? Proc Inst Mech Eng, Part H.2021; 235: 133–140.
Lewis G. Viscoelastic properties of injectable bone cements for orthopaedic applications: State-of-the-art review. J Biomed Mater Res, Part B. 2011; 98B(1): 171-191.
Stojkovic M, Milovanovic J, Vitkovic N, Trajanovic M, Grujovic N, Milivojevic V, Milisavljevic S, Mrvic S. Reverse modeling and solid free-form fabrication of sternum implant. Australas Phys Eng Sci Med. 2010; 33(3): 243-250.
Garcés GA, Rojas VH, Bravo C, Sampaio CS. Shear bond strength evaluation of metallic brackets bonded to a CAD/CAM PMMA material compared to traditional prosthetic temporary materials: an in vitro study. Dental Press J Orthod. 2020; 25(3): 31-38.
Reyes-Sevilla M, Kuijs RH, Werner A, Kleverlaan CJ, Lobbezoo F. Comparison of wear between occlusal splint materials and resin composite materials. J Oral Rehabil. 2018; 45(7): 539-544.
Zivic F, Babic M, Grujovic N, Mitrovic S, Favaro G, Caunii M. Effect of vacuum-treatment on deformation properties of PMMA bone cement. J Mech Behav Biomed Mater. 2012; 5(1): 129-138.
Kraaij G, Zadpoor AA, Tuijthof GJM, Dankelman J, Nelissen RGHH, Valstar ER. Mechanical properties of human bone–implant interface tissue in aseptically loose hip implants. J Mech Behav Biomed Mater. 2014; 38: 59-68.
Wimhurst JA, Brooks RA, Rushton N. The effects of particulate bone cements at the bone-implant interface. J Bone Jt Surg. 2001; 83-B(4): 588-592.
Sinnett-Jones PE, Browne M, Moffat AJ, Jeffers JRT, Saffari N, Buffière J-Y, Sinclair I. Crack initiation processes in acrylic bone cement. J Biomed Mater Res A. 2009; 89A(4): 1088-1097.
Nguyen NC, Maloney WJ, Dauskardt RH. Reliability of PMMA bone cement fixation: fracture and fatigue crack-growth behaviour. J Mater Sci Mater Med. 1997; 8(8): 473-483.
Shih C-C, Shih C-M, Su Y-Y, Lin S-J. Potential risk of sternal wires. Eur J Cardiothorac Surg. 2004; 25(5): 812-818.
Geringer J, Pellier J, Cleymand F, Forest B. Atomic force microscopy investigations on pits and debris related to fretting-corrosion between 316L SS and PMMA. Wear. 2012; 292-293: 207-217.
Koistinen AP, Korhonen H, Kröger H, Lappalainen R. Interfacial sliding properties of bone screw materials and their effect on screw fixation strength. J Appl Biomater Func. 2014; 12(2): 90-96.
Takamizawa T, Barkmeier W, Tsujimoto A, Scheidel D, Erickson R, Latta M, Miyazaki M. Mechanical Properties and Simulated Wear of Provisional Resin Materials. Oper. 2015; 40(6): 603-613.
Alexeev AA, Bolshev KN, Ivanov VA, Syromyatnikova AS, Bolshakov AM, Andreev AS. Experimental Study of Crack Branching Velocity in Polymers. Inorg Mater. 2019; 55(15): 1476-1480.
Koch S, Meunier M, Hopmann C, Alperstein D. A combined experimental and computational study of environmental stress cracking of amorphous polymers. Polym Adv Technol. 2020; 31(2): 297-308.
Zivic F, Babic M, Mitrovic S, Vencl A. Continuous control as alternative route for wear monitoring by measuring penetration depth during linear reciprocating sliding of Ti6Al4V alloy. J Alloys Compd. 2011; 509(19): 5748-5754.
Arnold JC, Venditti NP. Effects of environment on the creep properties of a poly(ethylmethacrylate) based bone cement. J Mater Sci: Mater Med. 2001; 12(8): 707-717.
Myshkin NK, Pesetskii SS, Grigoriev AY. Polymer Tribology: Current State and Applications. Tribol Ind. 2015; 37(3): 284-290.
Tiainen V. Amorphous carbon as a bio-mechanical coating — mechanical properties and biological applications. Diamond Relat Mater. 2001; 10(2): 153-160.
Gorham DA, Salman AD, Pitt MJ. Static and dynamic failure of PMMA spheres. Powder Technol. 2003; 138(2-3): 229-238.
Pulos GC, Knauss WG. Nonsteady crack and craze behavior in PMMA under cyclical loading: I. Experimental preliminaries. Int J Fract. 1998; 93(1/4): 145-159.
Etienne S, Becker C, Ruch D, Grignard B, Cartigny G, Detrembleur C, Calberg C, Jerome R. Effects of incorporation of modified silica nanoparticles on the mechanical and thermal properties of PMMA. J Therm Anal Calorim. 2007; 87(1): 101-104.
Geringer J, Atmani F, Forest B. Friction–corrosion of AISI 316L/bone cement and AISI 316L/PMMA contacts: Ionic strength effect on tribological behaviour. Wear. 2009; 267(5-8): 763-769.
Munir S, Walsh WR. The Quantification of Corrosion Damage for Pre-stressed Conditions: A Model Using Stainless Steel. Journal of Bio- and Tribo-Corrosion. 2016; 2(1): 4.
Ayre WN, Denyer SP, Evans SL. Ageing and moisture uptake in polymethyl methacrylate (PMMA) bone cements. J Mech Behav Biomed Mater. 2014; 32: 76-88.
Savio JA, Overcamp LM, Black J. Size and shape of biomaterial wear debris. Clin Mater. 1994; 15(2): 101-147.
Capitanu L, Badita L-L, Florescu V. Stability Loss of the Cemented Stem of Hip Prosthesis due to Fretting Corrosion Fatigue. Tribol Ind 2017; 39(4): 536-546.
De Baets T, Waelput W, Bellemans J. Analysis of third body particles generated during total knee arthroplasty: Is metal debris an issue? The Knee. 2008; 15(2): 95-97.
